KBDA Digital Drive - NEMA 4X / IP 65 VFDs

KB’s AC VFDs provide variable speed for 3ph AC Induction motors from 1/8 through 5 horsepower. For OEM applications, custom drives are also available for Brushless DC, PMSM, PSC, and Shaded Pole motors. They are available in 115, 208/230, and 400/460 VAC - 50/60 Hz with 1ph and 3ph input.

All KB’s AC Drives contain Sensorless Flux Vector Compensation with Static-Auto-Tune. This provides excellent speed regulation from zero to full load over a wide frequency range. These drives provide auto energy savings at light loads and smooth motor torque operation.

A variety of optional VFD accessories are also available to meet the most demanding applications.

Click here for more information

KBDA Digital Drive - NEMA 4X / IP 65

The KBDA Series of Digital Adjustable Frequency Drives consist of eight inverter models rated for 1/8 to 5 horsepower motors. These drives are housed in heavy duty NEMA 4X / IP 65 die-cast aluminum washdown/watertight enclosures for indoor or outdoor use. More Information:

Options:

  • IODA Input/Output Multi-Function Module
  • Modbus Serial Communication Module
  • Drive-Link™ Programming Kit
  • On/Off AC Line Switch
  • Class “A” (CE) RFI Filter and Liquidtight Fittings.
Digital - AC Controls, Nema-4X
Model No.
Rating
Part No.
Data Sheet
Manual
Details
115/230 Volts AC 1Ø Input
KBDA-24D Gray 1.0 HP, 3.6A, 230 VAC 3ø Output 9536 Data Manual Details
KBDA-24D White 1.0 HP, 3.6A, 230 VAC 3ø Output 9537 Data Manual Details
KBDA-27D Gray 2.0 HP, 6.7A, 230 VAC 3ø Output 9543 Data Manual Details
KBDA-27D White 2.0 HP, 6.7A, 230 VAC 3ø Output 9544 Data Manual Details
230 Volts AC 1Ø Input
KBDA-29 (1P) Gray 3.0 HP, 9.0A, 230 VAC 3ø Output 10003 Data Manual Details
KBDA-29 (1P) White 3.0 HP, 9.0A, 230 VAC 3ø Output 10004 Data Manual Details
230 Volts AC 3Ø Input
KBDA-24P Gray 1.0 HP, 3.6A, 230 VAC 3ø Output 9766 Data Manual Details
KBDA-24P White 1.0 HP, 3.6A, 230 VAC 3ø Output 9767 Data Manual Details
KBDA-29 Gray 3.0 HP, 9.0A, 230 VAC 3ø Output 9545 Data Manual Details
KBDA-29 White 3.0 HP, 9.0A, 230 VAC 3ø Output 9546 Data Manual Details
380/460 Volts AC 3Ø Input
KBDA-42 Gray 1.0 HP, 2.0A, 460 VAC 3ø Output 9763 Data Manual Details
KBDA-42 White 1.0 HP, 2.0A, 460 VAC 3ø Output 9764 Data Manual Details
KBDA-45 Gray 3.0 HP, 4.6A, 460 VAC 3ø Output 9659 Data Manual Details
KBDA-45 White 3.0 HP, 4.6A, 460 VAC 3ø Output 9660 Data Manual Details
KBDA-48 Gray 5.0 HP, 8.3A, 460 VAC 3ø Output 9661 Data Manual Details
KBDA-48 White 5.0 HP, 8.3A, 460 VAC 3ø Output 9662 Data Manual Details
